Front view option:

PM-80DLR functions as a rear-view camera as standard. For front view application, please cut the thin WHITE wire near the camera lead and restart power to see the image reversed.

Guideline option:

PM-80DLR has parking guidelines as a default. To remove guidelines, cut the thin GREEN wire near the camera lead and the guidelines will now be removed.

Wiring the camera:

To wire this camera to your Parkmate display, please ensure that you see the notice below:

• Please read this manual carefully before using the product.
• Wire connection points should always be insulated.
• Wiring should always be installed away from heat sources and electrical components.
• Please perform tests after finishing installation to ensure camera is working correctly.
• This camera is intended for use as an aid when reversing your vehicle. Drivers must always use extreme caution when operating a vehicle.
• Specifications are subject to change without notice

Please seek a professional when wiring the camera to the monitor. If you wish to complete this on your own, see the illustration below.

Put the car into reverse to test the performance of the camera.
